Technical Specification
|
Fluid |
Air ,if use liquid please contact factory |
|
|
Max.working Pressure |
1.32Mpa(13.5kgf/cm?) |
|
|
Pressure Range |
Normal Working Pressure |
0-0.9 Mpa(0-9.2kgf/cm?) |
|
Low Working Pressure |
-99.99-0Kpa(-750~0mmHg) |
|
|
Ambient Temperature |
0-60? |
|
|
Applicable Pipe |
PU Tube |
|
|
Material |
Zinc Alloy |
|
| Model | P | A | ?B | C1 | C2 | L |
| BLSP-10 | 6 | 11 | 18 | 10 | 14 | 42 |
| BLSP-20 | 8 | 13 | 18 | 13 | 14 | 43 |
| BLSP-30 | 10 | 14 | 18 | 15 | 15 | 44 |
